Availability: | |
---|---|
Features
3CCT, 4Watt tunable
IP65 led non corrosive
IK08 Rating
2ft, 4ft, 5ft
Input: AC220-240V, 120-277V, 50/60HZ, 120-347V as optional
Perfect replacement for the whole set of T8 fluorescent luminaire
Built-in sensor is optional. Emergency battery back up available
Work in -40°C ~+40°C temp
Application
Typical applications include commercial and manufacturing facilities, Parking Garages, warehouse lighting fixtures, and retail aisles.
Warehouses, factories & food storage
Refrigerated Storage
Farm
Specially used in some indoor industry lighting environments
Accessories
External sensor | Built in sensor | Plug and mounting clips |
Features
3CCT, 4Watt tunable
IP65 led non corrosive
IK08 Rating
2ft, 4ft, 5ft
Input: AC220-240V, 120-277V, 50/60HZ, 120-347V as optional
Perfect replacement for the whole set of T8 fluorescent luminaire
Built-in sensor is optional. Emergency battery back up available
Work in -40°C ~+40°C temp
Application
Typical applications include commercial and manufacturing facilities, Parking Garages, warehouse lighting fixtures, and retail aisles.
Warehouses, factories & food storage
Refrigerated Storage
Farm
Specially used in some indoor industry lighting environments
Accessories
External sensor | Built in sensor | Plug and mounting clips |
Specification
Model Number | Power |
Lumen (lm) | Ra | Driver | CCT | Voltage | Size
| PF |
R6E-2VTM18W-XXK | 23W/20W/17W/14W | 2875 | 80 | Non- isolated | 3000K/4000K/5700K in one fixture 3CCT | 220- 240V | 2FT | >0.9
|
R6E-4VTM35W-XXK | 35W/30W25W/20W | 4375 | 80 | 4FT | ||||
R6E-4VTM45W-XXK | 45W/38W/32W/26W | 5625 | 80 | 4FT | ||||
R6E-5VTM55W-XXK | 55W/47W/38W/32W | 6875 | 80 | 5FT |
Light Distribution Curve
Certification
ETL |
Specification
Model Number | Power |
Lumen (lm) | Ra | Driver | CCT | Voltage | Size
| PF |
R6E-2VTM18W-XXK | 23W/20W/17W/14W | 2875 | 80 | Non- isolated | 3000K/4000K/5700K in one fixture 3CCT | 220- 240V | 2FT | >0.9
|
R6E-4VTM35W-XXK | 35W/30W25W/20W | 4375 | 80 | 4FT | ||||
R6E-4VTM45W-XXK | 45W/38W/32W/26W | 5625 | 80 | 4FT | ||||
R6E-5VTM55W-XXK | 55W/47W/38W/32W | 6875 | 80 | 5FT |
Light Distribution Curve
Certification
ETL |
